ROG STRIX B760-A GAMING WIFI - Placa base ATX Intel B760 LGA 1700 de color blanco con 12+1 DrMos, DDR5, PCIe 5.0 SafeSlot, 3x PCIe 4.0 M.2, WiFi 6E, USB 3.2 Gen 2x2 Type-C, Aura Sync RGB

Características:

• Zócalo Intel® LGA 1700: Compatible con los procesadores Intel® Core™ de 12.ª y 13.ª generación, Pentium® Gold y Celeron®.
• Solución de alimentación optimizada: 12 + 1 etapas de potencia, conectores de alimentación ProCool, bobinas de aleación de alta calidad y condensadores resistentes para los procesadores multi-core más recientes.
• Refrigeración VRM optimizada: Los gruesos disipadores térmicos unidos al VRM con almohadillas térmicas de alta conductividad mantienen la solución fría durante cargas de trabajo intensas.
• Compatible con M.2: Tres ranuras PCIe 4.0 M.2 con disipadores térmicos mantienen temperaturas óptimas para la máxima velocidad de transferencia de datos.
• Redes de última generación: Intel Wi-Fi 6E (802.11ax) y Ethernet Intel 2.5G integrados con ASUS LANGuard
• Amplia conectividad: Puerto de E/S trasero USB 3.2 Gen 2x2 Tipo C®, ocho puertos USB adicionales, conector de panel frontal USB 3.2 Gen 2, PCIe 5.0 x16 SafeSlot, HDMI® 2.1 y DisplayPort™ 1.4.
• Control inteligente: AI Networking y cancelación de ruido AI bidireccional exclusivos de ASUS que simplifican la configuración y mejoran el rendimiento.
• Diseño DIY sencillo: PCIe Slot Q-Release, M.2 Q-Latch, BIOS FlashBack™ y Q-LED.
• Audio gaming líder del sector: ALC4080 con amplificador Savitech SV3H712, en conjunto con DTS® Sound Unbound™ y Sonic Studio III.
• Software reconocido: Suscripción de prueba de 60 días a AIDA64 Extreme e intuitivo panel de control UEFI BIOS con MemTest86 integrado.

Especificaciones ASUS ROG STRIX B760-A GAMING WIFI

•  CPU
  • Intel® Socket LGA1700 for 13th Gen Intel® Core™ & 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors
  • Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**
  • * Refer to www.asus.com for CPU support list.
  • ** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.
  • Chipset
  • Intel® B760 Chipset
• Memory
  • 4 x DIMM slots, Max. 128GB, DDR5
  • 7800+(OC)/7600(OC)/7400(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/ 6200(OC)/6000(OC)/5800(OC)/5600/5400/5200/5000/4800 Non-ECC, Un-buffered Memory*
  • Dual Channel Memory Architecture
  • Supports Intel® Extreme Memory Profile (XMP)
  • OptiMem II
  • * Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/
  • * Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.
• Graphics
  • 1 x DisplayPort**
  • 1 x HDMITM port***
  • * Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates. // Please refer to AMD CPU specifications.
  • ** Supports max. 4K@60Hz as specified in DisplayPort 1.4
  • *** Supports 4K@60Hz as specified in HDMI 2.1.
  • **** VGA resolution support depends on processors' or graphic cards' resolution.
• Expansion Slots
  • Intel® 13th & 12th Gen Processors
  • 1 x PCIe 5.0 x16 slot
  • Intel® B760 Chipset
  • 1 x PCIe 3.0 x16 slot (supports x4 mode)*
  • 2 x PCIe 3.0 x1 slots*
  • * PCIe x1(G3)_1 and PCIe x1(G3)_2 slots share bandwidth with PCIe x16(G3). When PCIe x1(G3)_1 or PCIe x1(G3)_2 slot is operating, PCIe x16(G3) will only supports x2 mode.
  • - To ensure compatibility of the device installed, please refer to https://www.asus.com/support/ for the list of supported peripherals.
• Storage
  • Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports*
  • Intel® 13th & 12th Gen Processors
  • M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
  • Intel® B760 Chipset
  • M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)
  • M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
  • 4 x SATA 6Gb/s ports
  • * Intel® Rapid Storage Technology supports SATA RAID 0/1/5/10.
• Ethernet
  • 1 x Intel® 2.5Gb Ethernet
  • ASUS LANGuard
• Wireless & Bluetooth®
  • Wi-Fi 6E
  • 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
  • Supports 2.4/5/6GHz frequency band*
  • Bluetooth® v5.3**
  • * WiFi 6E 6GHz regulatory may vary between countries.
  • ** The Bluetooth version may vary, please refer to the Wi-Fi module manufacturer's website for the latest specifications.
• USB
  • Rear USB (Total 9 ports)
  • 1 x USB 3.2 Gen 2x2 (20G) port (1 x USB Type-C®)
  • 1 x USB 3.2 Gen 2 (10G) port (1 x Type-A)
  • 3 x USB 3.2 Gen 1 (5G) port (2 x Type-A, 1 x USB Type-C®)
  • 4 x USB 2.0 ports (4 x Type-A)
  • Front USB (Total 6 ports)
  • 1 x USB 3.2 Gen 2 (10G) connector (supports USB Type-C®)
  • 1 x USB 3.2 Gen 1 (5G) header supports 2 additional USB 3.2 Gen 1 ports
  • 1 x USB 2.0 header and 1 x USB 2.0 5-1 pin header support 3 additional USB 2.0 ports
• Audio
  • ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080
  • - Impedance sense for front and rear headphone outputs
  • - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
  • - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input
  • - Supports up to 32-Bit/384 kHz playback
  • Audio Features
  • - SupremeFX Shielding Technology
  • - Savitech SV3H712 AMP
  • - Premium audio capacitors
  • - Dedicated audio PCB layers
  • - Audio cover
• Back Panel I/O Ports
  • 1 x USB 3.2 Gen 2x2 (20G) port (1 x USB Type-C®)
  • 1 x USB 3.2 Gen 2 (10G) port (1 x Type-A)
  • 3 x USB 3.2 Gen 1 (5G) ports (2 x Type-A, 1 x USB Type-C®)
  • 4 x USB 2.0 ports (4 x Type-A)
  • 1 x DisplayPort
  • 1 x HDMITM port
  • 1 x Wi-Fi Module
  • 1 x Intel® 2.5Gb Ethernet port
  • 5 x Audio jacks
  • 1 x BIOS FlashBack™  button
• Internal I/O Connectors
  • Fan and Cooling related
  • 1 x 4-pin CPU Fan header
  • 1 x 4-pin CPU OPT Fan header
  • 1 x 4-pin AIO Pump header
  • 4 x 4-pin Chassis Fan headers
  • Power related
  • 1 x 24-pin Main Power connector
  • 1 x 8-pin +12V Power connector
  • 1 x 4-pin +12V Power connector
  • Storage related
  • 3 x M.2 slots (Key M)
  • 4 x SATA 6Gb/s ports
  • USB
  • 1 x USB 3.2 Gen 2 (10G) connector (supports USB Type-C® )
  • 1 x USB 3.2 Gen 1 (5G) header supports 2 additional USB 3.2 Gen 1 ports
  • 1 x USB 2.0 header and 1 x USB 2.0 5-1 pin header support 3 additional USB 2.0 ports
  • Miscellaneous
  • 3 x Addressable Gen 2 headers
  • 1 x Aura RGB header
  • 1 x Clear CMOS header
  • 1 x Front Panel Audio header (AAFP)
  • 1 x S/PDIF Out header
  • 1 x 20-5 pin System Panel header
  • 1 x Thermal Sensor header
  • 1 x Thunderbolt™ (USB4®) header
• Special Features
  • Extreme Engine Digi+
  • - 5K Black Metallic Capacitors
  • ASUS Q-Design
  • - M.2 Q-Latch
  • - PCIe Slot Q-Release
  • - Q-DIMM
  • - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
  • - Q-Slot
  • ASUS Thermal Solution
  • - M.2 heatsink
  • - VRM heatsink design
  • ASUS EZ DIY
  • - BIOS FlashBack™ button
  • - BIOS FlashBack™ LED
  • - CPU Socket lever protector
  • - ProCool
  • - Pre-mounted I/O shield
  • - SafeSlot
  • - SafeDIMM
  • Aura Sync
  • - Aura RGB header
  • - Addressable Gen 2 headers
• Software Features
  • ROG Exclusive Software
  • - GameFirst VI
  • - ROG CPU-Z
  • - Sonic Studio III + Sonic Studio Virtual Mixer + Sonic Suite Companion
  • - Sonic Radar III
  • - DTS® Sound Unbound
• ASUS Exclusive Software
  • Armoury Crate
  • - AIDA64 Extreme (60 days free trial)
  • - Aura Creator
  • - Aura Sync
  • - Fan Xpert 4
  • - Power Saving
  • - Two-Way AI Noise Cancellation
  • - Performance and Power Saving Utility
  • AI Suite 3
  • - DIGI+ VRM
  • - PC Cleaner
  • MyAsus
  • Adobe Creative Cloud (Free Trial)
  • WinRAR
  • UEFI BIOS
  • ASUS EZ DIY
  • - ASUS CrashFree BIOS 3
  • - ASUS EZ Flash 3
  • - ASUS UEFI BIOS EZ Mode
  • MemTest86
• BIOS
  • 256 Mb Flash ROM, UEFI AMI BIOS
• Manageability
  • WOL by PME
• Accessories
  • Cables
  • 2 x SATA 6Gb/s cables
  • Additional Cooling Kit
  • 1 x Thermal pad for M.2
• Miscellaneous
  • 1 x ASUS Wi-Fi moving antennas
  • 1 x Cable ties package
  • 1 x M.2 Q-Latch package
  • 1 x ROG key chain
  • 1 x ROG Strix stickers
  • 1 x ROG Strix thank you card
  • 1 x M.2 Rubber Packages
• Documentation
  • 1 x User guide
• Operating System
  • Windows® 11, Windows® 10 64-bit
• Form Factor
  • ATX Form Factor
  • 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
